cs12-凯发k8官方

touring performance

coaxial structure to optimize directivity

stage monitor or small

foh

monitor level frequency response ,minimum

squeal

75mm large-size neodymium hf driver

frequency respond

60 hz ~ 18 khz(±3 db) ; 45 hz ~ 18 khz(-10 db)

nominal coverage(- 6 db)

80°(h) 80°(v)constant directivity

sensitivity(@1w/1m)

96 db spl

powerating(aes)

450 w

nominal impedance

8 ω

maximum spl

122 db spl(continuous) 128 db spl (peak)

drivers

lf:1 x 12" (75 mm voice coil)woofer

hf:1 x 3" (75 mm voice coil)neodymium compression

driver

dimension( h x w x d)

600×395×395 mm

weight

25kg

speaker cables

1 1-(signal input & loop)

connectors

2 x nl4mp neutrik speakon connectors

materials

18 mm birch plywood

finish

black polyurea coatings

grille

porous steel mesh with black spraying
