applications | feature |
outdoor | unique hdwt high density waterproof technology |
all-weather | cp anticorrosive metal treatment technology |
waterscape | the surface of component is wrd waterproof adhesive |
theatre | using ade acoustics special cloth edge driver, thick and elastic listening |
multi-function hall | ap acoustics professional birch plywood |
disco | vented subwoofer |
club | 18"direct- radiation driver |
kuba | heat resisting 4" (100mm)voice coil |
technical specification | |
frequency respond | 32 hz ~ 180 hz (±3 db);30 hz ~ 250 hz (-10 db) |
sensitivity | omnidirectional |
nominal coverage(- 6 db) | 102 db spl |
powerating(aes) | 2400 w(continuous);9600 w(peak) |
nominal impedance | 4 ω |
maximum spl | 135 db(continuous);141 db(peak) |
drivers | 2 x 18"(100 mm voice coil)woofer |
physical data | |
dimension( h x w x d) | 580 x 1160 x 924 mm |
weight | 76 kg |
connectors | 2 x wp4 waterproof connectors |
speaker cables | 1-2 |
materials | ap acoustics professional birch plywood |
finish | treatment of hdwt high density waterproof technology |
grille | aluminum mesh sound-permeable waterproof mesh fabric |
level of protection | ip56 |
