sp10 10-凯发k8官方

outdoor

unique hdwt high density waterproof technology

all-weather

cp anticorrosive metal treatment technology

waterscape

the surface of component is waterproof with wrd waterproof adhesive

theatre

uce point sound source uniform energy cover technology

multi-function hall

odc point source directivity optimization control technology

bar

frequency response special design to avoid auditory fatigue

rotatable and asymmetrical horn

13x m8 rigging points

pole mount socket

frequency respond

70 hz ~ 18 khz (±3 db)；55 hz ~ 20 khz (-10 db)

nominal coverage(-6db)

50°-100°(h)；55°(v) constant directivity

sensitivity

95 db spl

powerating(aes)

350 w(continuous);1400 w(peak)

nominal impedance

8 ω

maximum spl

120 db(continuous);126 db(peak)

drivers

hf  1 x 44 mm compression driver

lf  1 x 10"(75 mm voice coil)woofer

dimension( h x w x d)

582 x 310 x 321 mm

weight

19 kg

connectors

2 x wp4 waterproof connectors

speaker cables

1-2

materials

ap acoustics professional birch plywood

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

level of protection

ip56
