sj108 single 8-凯发k8官方

outdoor

unique hdwt high density waterproof technology.

all-weather

cp anticorrosive metal treatment technology.

waterscape

the surface of component is waterproof with wrd waterproof adhesive.

theatre

patented technology of cwg plane wave generator.

multi-function hall

spct phase correction patent technology.

church

smooth frequency and phase response.

small scale single-way drive full-frequency system.

a two-channel power amplifier can push 8 sj108.

frequency respond

80 hz ~ 16 khz (±3db)；70 hz ~ 18 khz (-10db)

nominal coverage(-6db)

90°(h)；10°(v) adjustable

sensitivity

97 db spl

powerating(aes)

250 w(continuous);1000 w(peak)

nominal impedance

16 ω

maximum spl

121 db(continuous);127 db(peak)

drivers

hf:1×3" (75mm voice coil) driver

lf:1×8"(50mm voice coil)woofer

dimension( h x w x d)

305 x 622 x 360 mm

weight

23kg

connectors

2 x wp4 connectors

speaker cables

1-2 (built-in frequency division full frequency input)

materials

aabp composite aluminum alloy birch board box

finish

treatment of hdwt high density waterproof technology

grille

aluminum mesh sound-permeable waterproof mesh fabric

rigging

0°,2°,4°,6°,8°,10° degree adjustable

level of protection

ip56
