pl-1502 computer moving head beam light

technology parameter:

input voltage: 220v, 50hz

power rating: 1500w

light source: osram double-end bubble, color temperature 6500k

life: 750 hours

ballasts: inductance ballast

cmy: italy odl cmy, linear color mixing system

color wheel: 8 replaceable colors white light, flowing position function

gobo wheel ι: 6 fixed pattern white light, shaking, pattern with optional positioning function

gobo whee п: 6 rotatable and replaceable pattern white light, shaking, pattern with optional positioning function, two-way rotating flow function

prism: 3-facet prism, two-way rotation, positioning function

frost: 0 to 100% linearly adjustable

focus: inductive focus

dimmer: 0 to 100% linearly adjustable

strobe: double blade, adjustable speed(1 to 13s)

iris: electric, linear

beam angle: parallel beam, 5°

head movement: pan 630°, tilt 275°

control: 3pins and 5 pins dmx512 interface

channels: 19/21/32 chs

other functions: 30 default cmy , color mixing and color macro run saynchronously, the rotating pattern and fixed pattern have the function of simutaneously focusing

half power function: close the brake, work in 50% power

net weight: 32kgs

gross weight: 60kgs

size: 73×53×76 cm

channel form
