pl-1501 computer moving head wash light

technology parameter:

input voltage: 220v, 50 / 60hz

ballasts: inductance ballast

power rating: 1500w

light source: philips msr gold 1200 sa, color temperature 6000k, life expectancy:750hours

cmy: cmy linear color mixing with comb structure, built-in cmy macro function ,pan/tilt resolution: 16 bit

color wheel: 2 color plate, each group has 6 replaceable filter

frost: 0 to 100% independence, adjustable

zoom: 10° to 44°, depends on the filter type

dimmer: 0 to 100% linearly adjustable

strobe: adjustable speed

head movement: pan530°, tilt280°

control : 3 pins and 5 pins dmx 512 interface

protocol: usitt dmx-512

channels: 17, 21, 23, 24, 30

half power mode: when the dimmer is closed, the energy-saving is supported, or all the cmy color plate is closed(black), the bulb’s power consumption will reduce 50% automatically to extend it’s life and improve the stability

display: lcd display supports chinese and english

net weight: 48kgs

gross weight: 90kgs

size: 67×61×90 cm

channel form
