pl-575 computer moving head pattern light

technology parameter

input voltage: ac 100-240v, 50 / 60hz

ballasts: inductance ballast

light source: philips msr 575/2 mini fastsit, color temperature 7200k,  life expectancy：1000hours

color wheel ι: 9 discs white light, adjustable speed and rainbow effect

color wheel п: 9 discs white light, 3200k and 5600k color temperature converter

gobo wheel ι: 6 rotatable pattern white light，two-way rotation

gobo wheel п: 9 patterns white light, shaking and rotation effect

focus: 0 to 100% linearly focus

prism: 3-facet prism rotating in both directions，positioning function

dimmer: two-plate dimming, 0 to 100%  linearly adjustable

strobe: adjustable speed( 0.3 to 10 times/s), double guillotine/shading

display: 4-bits led, adjust address, special function and effect regulation

beam angle: parallel beam, 18° view angle

head movement: pan 540°, tilt 270° with auto position correction

control : 3 pins and 5 pins dmx512 interface

protocol: usitt-dmx-512

channels: 16/14 channels

net weight: 34kgs

gross weight: 36kgs

size: 54×53×66 cm

channel form
