subwoofer with ls210

soft and low frequency elastic

stadium

75mm voice coil long throw high power lf

driver

small volume, vented, horn preposition

design

frequency respond

38 hz ~ 200 hz(±3 db) ; 25 hz ~ 320 hz(-10 db)

nominal coverage(- 6 db)

omnidirectional

sensitivity(@1w/1m)

102 db (40 hz ~ 200 h)

powerating(aes)

1200 w

nominal impedance

8ohm

maximum spl

133 db spl,139 db spl peak

drivers

2×15"(75mm voice coil) woofer

dimension( h x w x d)

606.5×700×700 mm

weight

65kg

speaker cables

1-2 (signal input & loo)

connectors

2 x wp4 connectors

materials

18 mm birch multi-plywood splints

finish

black polyurea coatings

grille

porous steel mesh with black spraying

rigging

0°
