ls110s-凯发k8官方

touring performance

75mm voice coil high-transient response woofer

theatre and multi-function hall

small volume, vented, horn preposition design

church

small enclosure but high spl output

frequency respond

40 hz ~200 hz(±3 db);30 hz ~320 hz(-10 db)

nominal coverage(- 6 db)

omnidirectional

sensitivity(@1w/1m)

100 db spl

powerating(aes)

1000 w

nominal impedance

8 ω

maximum spl

130 db（continuous）136 db（peak）

drivers

2 x 15"（75mm voice coil) woofer

dimension( h x w x d)

650×580×796 mm

weight

60kg

speaker cables

1-2 （signal input & loop）

connectors

2 x wp4 connectors

materials

15 mm，18 mm  birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying

rigging

5、0、-5、-10°degree adjustable
