es-08 emergency switche

features:

※es-08 is 8-channel two-channe signal input.

※broadcast-level audio quality.

※working level up to 24dbu.

※specially design for the radio and television system.

※standard 2u-19 inch rack airframe.

※front and rear panels can also be installed on the rack.

※highly integrated, rugged all-metal organism.

※military indicators accessories manufacturing

front panel setting

toggle switch

switch light

es-08 qian.jpg

rear panel setting

i/p-a signal input

i/p-b signal input

o/p signal output

power1/2 dual power supply input

control external remote interface

cascade cascade connection control interface

frequency response	0db 20hz ~ 20khz 0db
input level	max 40dbu
total harmonic distortion degree	0.00035%(0 dbu 1khz)
loss attenuation	0db 600 ohm load (in most high impedance input devices, can be considered without attenuation loss
output short circuit	0db
size	483(w)x88(h)x328(d)mm
weight	4kg
