small format, high pressure powered stereo system
while the smallest of the axle line, the axle-krx202 can pack a punch. composed of one dragon-kx12 18" coaxial loudspeaker paired with a thunder-kmt18 18” subwoofer per side in a stereo configuration, the krx202 is an aggressive, small format portable system that produces high pressure in the near field.
ideal applications are dj use, small clubs and lounges, and event productions.
features
unique performance-to-size ratio
color customizable
integrated dsp
dante compatible
four-corner port configuration
selectable coverage
self-powered capabilities
onboard touch screen
applications
theatrical reinforcement
concert halls
av system
movie and special effects
religious venues
clubs
bars
yacht
restaurants
touring and fixed film and television system
theatre
specifications
rumble-kmt181
acoustics | |
power handling | 800 w (aes) |
impedance | 8 ohm |
frequency range | 30 hz - 150 hz ± 3db (preset relating) |
maximum spl | 130 db continuous - 136 db peak |
coverage | |
horizontal | omni° |
vertical | omni° |
crossover | |
coaxial | dsp controlled |
frequency | 150 hz (preset dependent) |
transducers | |
full-range | 1 x 18” neodymium speakers with 3” voice coil |
amplifiers | |
type | 1 modules class d - dsp controlled |
power | 2x1000 watt @ 8ω |
protection | dynamic limiter, over current, over temp, short circuits |
dragon-kx12
acoustics | |
power handling | 800 200 w |
impedance | 8 ohm |
frequency range | 120 hz - 19 khz |
maximum spl | 127 db continuous - 133 db peak |
coverage | |
horizontal | 100°/30° (depending on horn orientation) |
vertical | 30°/100° (depending on horn orientation) |
crossover | |
coaxial | external crossover required |
frequency | 12” neodymiun magnet woofer with 3” voice coil neodymium magnet compression driver with 2”voice coil |
power audio imput | |
connectors | 2 x 4-pin speakon |
wiring | 1 1- (signal in & link ) 2 2- (through) |
recommended amplifiers | |
type | kmt18, kmt21, kmt218, ka84 neodymium magnet compression driver with 2”voice coil |
physical overview | |
dimensions | 34.0 x 32.0 x 20.0 cm (13.38”x 12.59”x 7.87”) (1) |
weight | 12.2 kg (26.89 lb) |
