f350

凯发k8官网的产品展示图 fm功放系列 f350.jpg

fineamp amplifier is designed with the aim to make stable and true sound with full consideration to customers' concerns. it applies neutrik connector for input and output, uses japanese elna audio coupling capacity. and it features h class circuit with excellent and stable sound quality. the max output is 1500w/8ohm (per ch).huge capacity power supply, high-quality component and efficient cooling system have completely ensured fineamp amplifier's excellent stability. during r&d, our engineers found power transformer, filter capacitor, coupling capacitance, input volume poten-tiometer, even input opamp ic ceramic capacitor etc. will have audible influence to sound quality obviously. to improve sound quality, it's not just choosing branded power tube. actually, there're many factors affecting sound fidelity, so we have tested each factor and compared carefully, finally found the best answer. this comparison and test procedure is a long time of fineamp r&d.our engineer's determination for perfect sound has make fineamp amplifier's quality achieved an unprecedented standard.


f350

350w/8ω

600w/4ω

★technical specifications


frequency response

20hz~25khz±0.5db

thd n(rated power,4ω/khz)%

0.1%

signal noise ratio(db)

95db

connectors


input connectors

3-pinxlr,electronically balanced

input impedance

20kω balanced/10kω unbalanced

output connectors

speakon connectors(neutrik)

★input power


power requirement

200-240v(50-60hz)

dimension


f350

482×495×88mm

weight


f350

17kg
