f10000

凯发k8官网的产品展示图 fm功放系列 f10000.jpg

★ high power density:

the f10000 delivers a total of 2x 4000w/4ohm in only 2u.

★ fineamp sound quality :

f10000 amplifiers maintain excellent sound quality, with transparent

mid- and high-frequency performance and new circuit designs

optimized for sustained low-frequency output.

★ regulated switch mode power supply

output power remains constant even with significant drops in the mains

voltage.

★ efficient cooling system★ adjustable parameters

★ xlr input and link connectors

★ heavy- duty binding post or speakon output connectors

★ comprehensive protection and warning

★2ch professional amplifier	f10000
★output power		★connectors
8ω stereo power	2×2400w	input connectors	3-pin xlr,electronically balanced
4ω stereo power	2×4000w	input impedance	20kω balanced/10ω unbalanced
8ω bridged mono power	1×8000w	output connectors	speakon connectors(neutrik)
4ω bridged mono power	1×12000w
★technical specification		★power
frequency response	20hz-25khz±0.5db	power requirement	200-240v～50-60hz
thd n(rated power,4ω/khz)%	0.1%	minimum voltage	180-260v～50-60hz
signal noise ratio(db)	98db	★dimension and weight
optional magnification	23,26,29,32,35,38,41,44db	dimension	483×377×88mm
		weight	13kg
