touring performance

large-scale , thri-amp, three-way line array

system.

stadium

mf & hf parts is coaxial structure to

optimise acoustic image.

theatre

neodymium high-sensitivity driver,

maximum headroom

frequency respond

50 hz ~ 16 khz(±3 db)；40 hz ~ 18 khz(-10 db)

nominal coverage(- 6 db)

90°(h)adjustable

sensitivity(@1w/1m)

hf:113 db spl mf:105 db spl lf:100 db spl

powerating(aes)

hf/mf/lf:160/350/800 w(aes)

nominal impedance

hf/mf/lf:16/16/12 ω

maximum spl

hf:135/141 db mf:130/136 db lf:129/135 db

drivers

lf:2 x 12" (75 mm voice coil) woofer

mf:1 x 10" (65 mm voice coil) mid range

hf:2 x 3" neodymium compression driver

dimension( h x w x d)

374.5×1000×550 mm

weight

63 kg

speaker cables

1-2 …lf，3-4 …mf，5-6 …hf

connectors

2 x wp7 connectors

materials

18 mm birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying

rigging

0、1、2、3、4、5、6、7.5°degree

adjustable
