bar

frequency response special design to avoid auditory fatigue

theatre

rotatable and asymmetrical horn

stage monitor

13x m8 rigging points

pole mount socket

frequency respond

60 hz ~ 18 khz(±3 db) ;  50 hz ~ 20 khz(-10 db)

nominal coverage(- 6 db)

50°-100°（h）55°(v) constant direction

sensitivity(@1w/1m)

96 db spl

powerating(aes)

400 w

nominal impedance

8 ω

maximum spl

122 db (continuous) 128 db (peak)

drivers

lf:1 x 12"（75 mm voice coil) woofer

hf:1 x 44 mm  voice coil compression driver

dimension( h x w x d)

576x372x384 mm

weight

23kg

speaker cables

1 1-（signal input & loop）

connectors

2 x nl4mp neutrik speakon connectors

materials

18 mm，24 mm birch plywood

finish

black water paintings

grille

porous steel mesh with black spraying
