long throw rubber edge lf driver

near-field sound

rotatable 80x50°directivity horn

frequency respond

55 hz ~ 18 khz(±3 db) ; 50 hz ~ 20 khz(-10 db)

nominal coverage(- 6 db)

80°(h)50°(v) constant directivity

sensitivity(@1w/1m)

92 db spl

powerating(aes)

400 w

nominal impedance

8ohm

maximum spl

118 db (continuous) 124 db (peak)

drivers

lf: 1x10"(75 mm voice coil)rubber edge woofer

hf: 1x1.75"(44 mm voice coil) diaphragm compression driver

dimension( h x w x d)

552x320x320 mm

weight

20kg

speaker cables

1 1-(signal input & loop)

connectors

2 x nl4mp neutrik speakon connectors

materials

18 mm multi-plywood

finish

black water paintings

grille

porous steel mesh with black spraying
