conference room

36mm hf compression driver

church

the frequency response will extend to 50

fill system

excellent vocal performan

frequency respond

90 hz ~ 18 khz(±3 db) ; 50 hz ~ 20 khz(-10 db)

nominal coverage(- 6 db)

80°(h)80°(v) constant directivity

sensitivity(@1w/1m)

93 db spl (90 hz~20 khz)

powerating(aes)

250 w

nominal impedance

8 ω

maximum spl

117 db (continuous) 123 db (peak)

drivers

lf:1 x 8" driver

hf:1 x 36 mm diaphragm compression driver

dimension( h x w x d)

428×259×259 mm

weight

9.8kg

speaker cables

1 1-(signal input & loop)

connectors

2 x nl4mp neutrik speakon connecto

materials

15 mm, 18 mm multi-plywood

finish

black water paintings

grille

porous steel mesh with black spraying

installation

standoff holes and for multiple flying points
